| Products Technical Specification | |
| Type | Isuzu ELF KV100 Truck QL1080BUKAY |
| Brand | ISUZU 4*2 |
| Cab | Power steering, Air Condition |
| Vehicle Description | |
| Overall dimensions（mm） | 6995*2260*2440 |
| Curb weight(vehicle) (kg) | 3250 |
| Loading capacity (kg) | 5000-6000 |
| Max speed (Km/h) | 95-120 |
| Engine | |
| Mode | ISUZU 4KH1CN6LB |
| Type | Diesel, 4-cylinder in line with water cooling, |
| turbo-charging | |
| Max. power/rotated speed | 88(KW) /120HP |
| Displacement(ML) | 2999 |
| Emission level | Euro 6 |
| Chassis Description | |
| Wheel base | 3815 |
| Front axle | 2T |
| Rear axle | 4.8T |
| Front tread / rear tread | 1385/1425 |
| Gear box | ISUZU MSB 5-speed |
| Brake system | Oil brake belt vacuum booster pump |
| Electric system | 24V |
| Tyres | 7.50R16 |
| low cargo deck | 5170*2150*380mm |
| Serial | Wheelbase | Cabin/frame width | 120-32HP ISUZU KV100 Truck Model | Oil Brake or Blackout brake | ||||||
| 120HP 4KH1CN6LB | 132HP 4KH1CN6HB | |||||||||
| 7.00R16 | 7.50R16 | |||||||||
| ISUZU KV100 | 2765 | single cabin/700 | QL1073BUFACY | ISUZU KV100P/ ISUZU KV600 chassis with ISUZU 700 cabin: 120 HP ISUZU 4KH1CN6LB engine with ISUZU 5-speed transmission, 132 HP ISUZU 4KH1CN6HB engine with ISUZU 6-speed transmission, Equipped with air conditioning, steering assistance, multifunctional LCD instrument panel, Front axle Loading 3 tons, rear axle Loading 5 tons, with ABS, Air brake (or oil brake), the cab can be flipped, The 700mm beam with 700R16 tires and the frame height of 176mm, The 800mm beam With 750R16 tires and the frame height of 216mm. |
||||||
| 2795 | single cabin/800 | QL1080BUFAY | QL1080BUFACY | |||||||
| 3360 | single cabin/700 | QL1043BUHAY | ||||||||
| single cabin/700 | QL1073BUHACY | |||||||||
| 3365 | single cabin/800 | QL1043BUHAY | QL1043BUHACY | |||||||
| single cabin/800 | QL1080BUHAY | QL1080BUHACY | ||||||||
| 3815 | single cabin/700 | QL1073BUKAY | QL1073BUKACY | |||||||
| single cabin/800 | QL1080BUKAY | QL1080BUKACY | ||||||||
| ··· | ··· | ··· | ||||||||
 |
 |
 |
 |
 |
 |
 |
| ISUZU KV100 Engine 4K engine Euro 6 Continuing the advantages of high reliability, high economy, and high power, while comprehensively upgrading its core performance, it can meet the usage needs of future blue label policies and high-end urban distribution customers |
ISUZU KV100 Chassis Lightweight chassis Adopting the three light technologies of "light design, light material, and light manufacturing", not only does it comply with Blue Label regulations, but it also reduces weight without compromising quality, with a weight reduction of over 15%, bringing many benefits to users |
We have 20 years of experience in exporting specialized vehicles and can provide customized export services according to user requirements.
|
