15000L ISUZU GIGA Aircraft Refueling Truck Aluminum alloy tank aviation kerosene transport vehicle Export to Oman

This ISUZU GIGA  Aircraft Refueling Truck, 240HP ISUZU 6 Cylinder engine, equipment  oil tanks, a pumping system, a control system, and an operating part, with functions such as filtration, metering, refueling, pumping, self circulation, and pressure control


ISUZU GIGA Aircraft Reufeling Tank Truck:

Safe and reliable operation;Accurate measurement and reliable control in accordance with quality control standards

Low pressure loss;Flexible operation and convenience reflecting ergonomics; Easy maintenance and testing.

ISUZU GIGA Aircraft Refueling Truck, Install well-known American brand products with a maximum flow rate of 1500 liters per minute and a normal working pressure between 0.50-0.70 Mpa

Refueling hose, refueling connector, and gravity refueling gun

(1) Equipped with one 1.5-hour 20 meter gravity refueling hose and refueling gun; Equipped with one 2.5-inch 25 meter refueling hose and pressure oil connector. The rated flow rate for pressure refueling is 1200 liters per minute.

(2) The conductivity of the refueling hose meets the latest standard requirements of API1529.

(3) The pressure refueling joint meets the requirements of HB6122 "General Technical Conditions for Aircraft Pressure Refueling Nozzles" and HB6130 "Outline Dimensional Standards for Aircraft Pressure Refueling Nozzles".
